Definition
GAWR
(lb.)
Models
Beam
drop (in)
“S” “C”
KPI
(in.)
Turn
Angle
Range º
Design Restriction
3.50 0.86 69.0 22-50 Max track at rated load = 84”
SMC = 31-36” for 4” spring, 30-37” for 3” spring
Bearing shoulder to bearing shoulder = 77.38”
Overall width = 96” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
Dual Steer Arm required with TPCS
E-1462I
5.00 0.86 69.0 22-50 Max track at rated load = 84”
SMC = 31-36” for 4” spring, 30-37” for 3” spring
Bearing shoulder to bearing shoulder = 77.38”
Overall width = 96” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
Dual Steer Arm required with TPCS
3.50 0.86 71.0 22-50 Max track at rated load = 86”
SMC = 31.5-38” for 4” spring, 30.5-39” for 3” spring
Bearing shoulder to bearing shoulder = 79.38”
Overall width = 98” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
Dual Steer Arm required with TPCS
3.74 0.86 71.5 22-50 Max track at rated load = 86”
SMC = 32-38.5” for 4” spring, 31-39.5” for 3” spring
Bearing shoulder to bearing shoulder = 79.88”
Overall width = 98.5” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
Dual Steer Arm required with TPCS
14600
E-1462W
5.00 0.86 71.0 22-50 Max track at rated load = 86”
SMC = 33-38” for 4” spring, 32-39” for 3” spring
Bearing shoulder to bearing shoulder = 79.38”
Overall width = 98” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
Dual Steer Arm required with TPCS
16000
I-160W 3.74 1.50 71.5 28-43
35-50
Max track at rated load = 85.25”
Allow track at 32.5” SMC = 85.75”
SMC = 32-36” for 4” spring
Bearing shoulder to bearing shoulder = 81.02”
Overall width = 102.36” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 58,850 lb.in.
Dual Steer Arm required
18000
I-180W 3.74 1.50 71.0 28-43
35-50
Max track at rated load = 90.50”
SMC = 32-36” for 4” spring
Bearing shoulder to bearing shoulder = 80.52”
Overall width = 102.36” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 58,850 lb.in.
Dual Steer Arm required
