Spicer Steer Axles Application Guidelines - Manual (Page 19)

AXAG400 – February 2007 front < 13 >
Definition
GAWR
(lb.)
Models
Beam
drop (in)
“S” “C”
KPI
(in.)
Turn
Angle
Range º
Design Restriction
3.50 0.86 69.0 22-55 Max track at rated load = 85.5”
SMC = 31-36” for 4” spring, 30-37” for 3” spring
Bearing shoulder to bearing shoulder = 77.38”
Overall width = 96” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
E-1322I
5.00 0.86 69.0 22-45 Max track at rated load = 85.5”
SMC = 31-36” for 4” spring, 30-37” for 3” spring
Bearing shoulder to bearing shoulder = 77.38”
Overall width = 96” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
3.50 0.86 71.0 22-55 Max track at rated load = 87.5”
SMC = 31.5-38” for 4” spring, 30.5-39” for 3” spring
Bearing shoulder to bearing shoulder = 79.38”
Overall width = 98.” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
3.74 0.86 71.5 22-55 Max track at rated load = 87.5”
SMC = 32-38.5” for 4” spring, 31-39.5” for 3” spring
Bearing shoulder to bearing shoulder = 79.88”
Overall width = 98.5” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
13200
E-1322W
5.00 0.86 71.0 22-50 Max track at rated load = 87.5”
SMC = 33-38” for 4” spring, 32-39” for 3” spring
Bearing shoulder to bearing shoulder = 79.38”
Overall width = 98” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
14000
I-140W 3.74 1.50 71.5 35-45
40-50
Max track at rated load = 86.8”
SMC = 32-36” for 4” spring
Bearing shoulder to bearing shoulder = 80.158”
Overall width = 98.5” nominal
Max Tire SLR = 21.5”
Max Power Steering torque = 43,050 lb.in.
