18
• Refit then tighten the filler/level plug then drive
head filler plug.
• Refit road wheels securing with spherical wash-
ers and wheel nuts. Remove supports and lower
vehicle to ground. Tighten wheel nuts to a torque
of 400-430 lbs. ft. (542-583 N•m).
Note: The wheel nuts should be checked and
tightened if necessary, shortly after initial operation.
Tightening Torque Table for Type
HS 515 SP, HD 519 SP,
HS 716 SQ, HD 719 SQ
Item
No. Description Torque
1 Planet carrier cover capscrew 66-71 lbs. ft.
(89-98 N•m)
9 Planet carrier set screw 22-27 lbs. ft.
(30-36 N•m)
17 Hub bearing retaining nut 238-263 lbs. ft.
(323-357 N•m)
22 Wheel nuts 400-420 lbs. ft.
(542-583 N•m)
34 Axle spindle retaining bolt 390-410 lbs. ft.
(529-556 N•m)
38 Planet carrier capscrew 91-101 lbs. ft.
(123-137 N•m)
39 Planet carrier drain capscrews 145-151 lbs. ft.
(196-218 N•m)
Sub Assembly - Planet Carrier Unit
• Place planet carrier with large diameter face up
with planet gear access hole facing the mechanic.
• Smear clean grease into bore of one planet gear.
• Insert planet gear and thrust washer into planet
carrier.
• Lightly oil O-ring and O-ring grove in planet pin
with clear gear oil then fit 'O'ring into planet pin.
• Insert planet pin, O-ring up into planet carrier and
through planet gear making sure to line up flat on
planet pin with hole in planet carrier for set
screw.
• Clean set screw threads with solvent then apply
Loctite 275. Drive screw into hole in planet
carrier and tighten to a torque of 22-27 lbs. ft.
(30-36 N•m) to secure planet pin assembly.
• Repeat operations for other two planet gear
assemblies.
• Stake screw in four places to lock in position.
• Coat thrust button bore, in planet carrier, with
Loctite 275 then fit thrust button.
Fitting Planet Carrier Unit/Final Assembly
• Fit thrust washer, then sun gear onto axle shaft,
then fit snap ring to secure.
• Apply clean gear oil to axle shaft inner splines.
Insert axle shaft assembly into axle spindle until
axle shaft splines are engaging with differential
gear splines.
• Coat hub mating face of planet carrier with
Loctite 515 joining planet carrier unit with hub
using chain hoist if required. Ensure planet gear
teeth mesh with sun gear.
• Fit planet carrier capscrews and hardened
washers, tighten to a torque of 91-101 lbs. ft.
(123-137 N•m).
• Fit drain capscrew and washer, tighten to a torque
of 145-161 lbs. ft. (196-218 N•m).
• Fit planet cover plate, secure with capscrew,
tightening to 66-72 lbs. ft. (89-98 N•m).
• Rotate both hubs until oil filler/level plug holes
are on axle center line, fill with oil until level with
bottom of level hole thread.
• Fill drive head with oil.
• Allow oil to settle for 15 minutes, then check oil
level again in both hubs and diff.
HS 515 SP, HD 519 SP,
HS716SQ, HD 719 SQ Models
