User manual for the ZEN 3-channel X-LMS controller Soft dB inc.
2.0 Software Installation
To install the ZEN controller software, click on Setup.exe on the installation CD. The
following files will be transferred to the PC:
File name Folder Description
ZEN_Ver3_x.exe C:\Program Files\ZEN_SoftdB PC user interface
SRanger2.dll C:\Program Files\ZEN_SoftdB
DLL (Dynamic
Linked Library) used
to communicate with
the DSP board
default.cfg C:\Program Files\ZEN_SoftdB
Default configuration
file for the controller
mainsetup.cfg C:\Program Files\ZEN_SoftdB
Default configuration
file for the user
interface
CodeControl_SR2.out C:\Program Files\ZEN_SoftdB
DSP code for the
controller
codeiden_sr2.out C:\Program Files\ZEN_SoftdB
DSP code for the
identification of the
control paths
CodeMute_SR2.out C:\Program Files\ZEN_SoftdB
DSP code for setting
all outputs to zero
SR2_Flash_Support.out C:\Program Files\ZEN_SoftdB
DSP code for
managing the DSP
board flash memory
SR2_FPGA_Support.out C:\Program Files\ZEN_SoftdB
DSP code for
managing the DSP
board FPGA
SR2Kernel_HostDownloa
d.out
C:\Program Files\ZEN_SoftdB
Communication DSP
code
SR2Kernel_PowerUp.out C:\Program Files\ZEN_SoftdB
Communication DSP
code
SR2_Analog_16.rbt C:\Program Files\ZEN_SoftdB
FPGA configuration
for the management
of the analog I/Os
ZEN_UserManual.pdf C:\Program Files\ZEN_SoftdB\doc
User manual for the
ZEN controller
SRm2.inf
C:\Program
Files\ZEN_SoftdB\DriverUSB
USB driver for the
SR Mk2
SRm2.sys
C:\Program
Files\ZEN_SoftdB\DriverUSB
USB driver for the
SR Mk2
ZEN User Manual p. 7
