4 quick start – Soft dB Opus Suite Building Acoustics Module Reverberation Time ISO 3382 User Manual
Page 8

7
4 Quick Start
Step 1
Select Measure Mode
Click on the
button to select the measure mode from the menu. The measure modes
are:
For purposes of example, select Manual Impulse from the menu. This mode does not require a
sound source and can be performed simply by clapping hands.
Step 2
Start the Measurement
Click on the
button to start the measurement. Follow the instructions in the status bar at
the top of the main interface.
Once the measurement process is complete, click on the
button to stop the
measurement.
Step 3
Save the Measurement
Click on the
button to save the measurement. The measurement file will be saved as a
.rt6 file in the file save directory. Its name will appear as a four digit number displayed in the File info
section of the main interface.
Waiting for stable floor noise
Ready for impulse
You can now clap your hands
Waiting for stable floor noise
1
2
3
4
Processing
5
Finished
6
