Page 11

10
5.1
Measure Controls
RUN/PAUSE/CONTINUE (Automatic mode)
When the user clicks this button, the measurement process is launched. The RUN
button then automatically becomes the PAUSE button.
When the user clicks this button, the measurement process is suspended. The PAUSE
button then automatically becomes the CONTINUE button
When the user clicks this button, the measurement process continues from where it
was suspended. The CONTINUE button then automatically becomes the PAUSE button.
RUN/ADD (Manual mode)
When clicked, this button starts the measurement. This button is then disabled until an
average iteration is complete. When an average iteration is complete, this button
becomes the ADD button.
This button is displayed and enabled while the manual measurement process is waiting
for another average iteration. When the user clicks this button, another average
iteration is launched. This button is the disabled until the average iteration is complete.
STOP/SAVE
When the user clicks this button, the measurement stops. The STOP button then
becomes the SAVE button.
When the user clicks this button, the active measurement is saved. The SAVE button is
then disabled until another measurement is complete.
5.2
File Info
File Save
This indicator displays the current measurement file.
Theses two buttons are used to open the next and previous files (respectively) in the
measurement save directory.
This indicator displays the next file to be saved.
5.3
Measure Info
Measure Info
This indicator displays the current measure mode. Clicking on this indicator launches
the setup interface, which allows the user to select a different measure mode.
This indicator displays the current average iteration and the specified average number.
Clicking on this indicator launches the setup interface where the average number can
