Relay Option Kit EN-1

1. INTRODUCTION

AC Relay Kit 80500720 and DC Relay Kit 80500727 are intended for use with the
Ohaus 5000 and 7000 Series Indicators. The AC relay kit is used to control up to
three external AC circuits. The DC relay kit is used to control up to three external DC
circuits. Each solid-state relay output is equivalent to a single pole, single throw

switch (SPST). Each relay circuit is protected by a replaceable fuse.

Applications include: driving external Over/Accept/Under displays, motor controls for
semi-automatic filling systems, sorting systems, interfacing to industrial PLC

systems, etc. The Relay outputs can also be used as slave relays to drive higher
power relays in larger systems.

Please read this manual completely before installation and operation.

CAUTION: READ ALL SAFETY WARNINGS BEFORE INSTALLING,
MAKING CONNECTIONS, OR SERVICING THE RELAY OPTION. FAILURE
TO COMPLY WITH THESE WARNINGS COULD RESULT IN PERSONAL

INJURY AND/OR PROPERTY DAMAGE. RETAIN ALL INSTRUCTIONS FOR
FUTURE REFERENCE.

1.1 Kit Contents

80500720


Common Parts

T51P, T71P parts
(bag marked "T--P")

T51XW, T71XW parts
(bag marked "T--XW")

• AC relay pc board

• Instruction manual

• Terminal cover

• Screws (6)
• Long cable
• Short cable
• Strain relief bushing

• Terminal cover

• Screws (6)
• Long cable
• Short cable
• Cable tie (2)

80500727


Common Parts

T51P, T71P parts
(bag marked "T--P")

T51XW, T71XW parts
(bag marked "T--XW")

• DC relay pc board

• Instruction manual

• Terminal cover

• Screws (6)
• Long cable
• Short cable

• Strain relief bushing

• Terminal cover

• Screws (6)
• Long cable
• Short cable

• Cable tie (2)
