Relay Option Kit EN-9

9 pin connectors Long cable Cable tie

Screws (4)

Relay pc

board

Terminal

blocks

Cable tie

Strain relief

bushing

Cable from

external

device

Connector

J8



Rear

housing

Cable

mount







Front

housing



Terminal

cover



Screws (2)

Figure 2.7. T51XW, T71XW
