MSD LS Coil Harness
PN 88867
ONLINE PRODUCT REGISTRATION: Register your MSD product online and you’ll be entered
in our monthly 8.5mm Super Conductor Spark Plug Wire give-away! Registering your product
will help if there is ever a warranty issue with your product and helps the MSD R&D team create
new products that you ask for! Go to www.msdignition.com/registration.
Parts Included:
1 - Harness
1 - Fuse Holder
This harness has been made by MSD to correct a check engine light issue that can arise in vehicles
using the MSD LS Coil Packs on their engines. This harness will supply additional battery voltage
to the coils in order to fire the coils properly and not drain other engine systems of power. This is
necessary do to the varying wire gauges used on production vehicles.
INSTALLATION
1. Locate the OEM harness that connects to the coil harnesses on each side of the top of the engine,
2. Unplug the coil harnesses from the OEM harness,
3. Use the new MSD harness to plug in and bridge between the OEM and coil harnesses,
4. Securely mount the attached relay,
5. Connect the included Orange wire to the positive battery terminal, and
6. Insert the included 20amp fuse into the box on the Orange wire.
Note: Be sure to always avoid heat sources, sharp objects, and sources of corrosives while routing
any wires.
Parts Bag:
1 - 20a Fuse
1 - Butt Connector
1 - Ring-lug
