18 INSTALLATION INSTRUCTIONS
M S D
• W W W . M S D P E R F O R M A N C E . C O M • ( 9 1 5 ) 8 5 7 - 5 2 0 0 • F A X ( 9 1 5 ) 8 5 7 - 3 3 4 4
AFTERMARKET COMPONENTS Wiring a Mallory Unilite or 9000 Series using Points Trigger.
RED
RED
IGNITION KEY
TO 12V TO GROUND
WHITE GREEN
BROWN
MALLORY
9000 SERIES
DISTRIBUTOR
W/MALLORY
UNILITE MODULE
WHITE
ORANGE
BLACK
MAGNETIC PICKUP
(NOT USED)
GRAY
TACH OUTPUT
GREEN (-) VIOLET (+)
DIGITAL 6AL
REV
LIMITER
Wiring a Toyota with a Tach Adapt PN 8910HEI. GENERAL IMPORT WIRING
ORANGE
(TO COIL +)
BLACK
(TO COIL -)
INDICATES CONNECTION
•
MAGNETIC PICKUP
(NOT USED)
GRAY
TACH OUTPUT
RED
WHITE
GREEN (-) VIOLET (+)
ORIGINAL COIL +
WIRE
ORIGINAL COIL -
TERMINAL
AMPLIFIER
DIGITAL 6AL
REV
LIMITER
NOTE: Remove the coil terminal wires. The negative
wire connects to MSD White. The positive wire
connects to MSD Red. The MSD Orange connects
to the coil positive terminal, Black connects to the
coil negative terminal.
