TC H-Pos
Description Defines the horizontal position of the TC on the screen.
Values 0 to 9
Default value 4
Name H-Pos
Description Defines the horizontal position of the edit name on the screen.
Values 0 to 15
Default value 0
TC V-Pos
Description Defines the vertical position of the TC on the screen.
Values 0 to 11
Default value 10
Name V-Pos
Description Defines the vertical position of the edit name on the screen.
Values 0 to 11
Default value 0
3.7.6. RS422 VarID Settings
User Interface
The RS422 VarID settings and the VDCP visibility settings display the read-only VarID
settings.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Protocol tab, on page 4 in the advanced display
mode in the server- and web-based interfaces.
Warning
The VDCP visibility settings are only available if the license code 119, required
to work with the VDCP protocol, is valid.
