5.3.4. Impact on the Channel Association with Recue
Mode ON
The Element is Inserted below the Cued Elements
The inserted element is assigned to the next channel in the ABCD order, based on the
previous element. The channels assigned to the elements below the inserted element are
resorted according to the ABCD sequence (ripple from the inserted element).
Initial situation RECUE Mode ON
Elem1 CUED A Elem1 CUED A
Elem2 CUED B Elem2 CUED B
Elem3 CUED C Elem3 CUED C
Elem4 CUED D Elem4 CUED D
Elem5 ON-LINE C Elem5 ON-LINE C
Elem6 ON-LINE B Inserted Elem ON-LINE D
Elem7 ON-LINE C Elem6 ON-LINE A
Elem7 ON-LINE B
The Element is Inserted above the Cued Elements
This case does not apply to the insertion of an element just before the first cued element.
The inserted element is assigned to the next channel in the ABCD order, based on the
previous element. The channel assignment of the cued elements is not modified, but it is
resorted for the elements after the cued ones (ripple for the elements below the cued
ones).
Initial situation RECUE Mode ON
Elem1 ON-LINE A Elem1 ON-LINE A
Elem2 ON-LINE B Inserted Elem ON-LINE B
Elem3 CUED C Elem2 ON-LINE B
Elem4 CUED D Elem3 CUED C
Elem5 CUED A Elem4 CUED D
Elem6 CUED B Elem5 CUED A
Elem7 ON-LINE D Elem6 CUED B
Elem8 ON-LINE C Elem7 ON-LINE C
Elem8 ON-LINE D
