Area Description
The table below describes the various parts of LSM Connect main window:
Part Name Description
1. Clip area Displays a view on the clips stored on the EVS server.
The clips can be displayed in grid view or list view .
2. Playlist area Displays a view on the visible playlists stored on the EVS server.
You can remove playlists from or add playlists to the list using the
Visible Playlist command at the bottom on the tab.
3. Toolbar area Displays metadata information of the element (playlist or clip)
selected in the clip or playlist area.
4. Command
bar Gives access to the following windows or commands:
allows you to select multiple elements in clip/playlist area.
allows you to lock the LSM Connect main window.
allows you to search for clips based on metadata.
allows you to open the Settings window.
Note
You can easily switch the position of the clip and playlist areas, or display two
clip or two playlist views at the same time by selecting the Clip tab or Playlist
tab on the upper left corner of area.
1.4. Selecting Items
How to Select One or Several Items
To select one clip, playlist or playlist elements, simply tap once on the requested item.
Double tap or tap and hold will not allow other types of selection.
To select several items, first tap the multi-selection icon , then select the requested
items.
Selected items have a blue background.
