6/1553-DBC 446 01 Uen E8 2010-07-08 16
D IALOG 5446 D ESCRIPTION
3.4 Indicator Lights
Instead of LED indicators on the phone keys, the IP phone has indicator
lights built into the display buttons. The indicator lights indicates line
status using different flash patterns, see below.
3.5 Tones and Signals
The Ring Signals settings page contains the Ring tone and Select Ring
Melody settings. You can choose between 10 different ring tones
(between 0 and 9) and a number of ring melodies. In order to distinguish
between internal, external and call back calls, the signal you choose will
be used with different ring cadences/characteristics for each call type.
You can also distinguish between callers by giving each phone number
its own ring signal.
This section describes the ring signals and tones characteristics avail-
able in the phone.
3.5.1 Tone Characteristics
The ring tones have the following cadences depending on the meaning:
Soft keyboard. The built-in soft keyboard appears as an
icon on pages where it is possible to enter text, for example
when you want to add a contact by typing the name and
number manually. Tap the icon to enlarge the keyboard. By
tapping the keyboard buttons at the bottom of the soft
keyboard, you can change character sets, and switch
between numbers and letters.
Free on 2nd line (Available in H.323 phones only). Enables
you to receive a second incoming call.
Callback. When you call a number and receive a busy tone,
or there is no answer, you can order automatic callback for
that number. As soon as the extension or line becomes free
(or, when there is no answer, when the extension has been
used), you will be called back.
Off Indicates idle status
Fast blinking Indicates an incoming call
Steady glow with fast blinking Indicates a busy line
