24 Rev. 5
Operation
Energizing Power Supply System Components
Note
If turned off, the Model 430 Programmer must remain unpowered
for at least 5 seconds before it is powered back on. If not, there may
be an initialization error, in which case the following screen will be
displayed.
If this occurs, turn the Model 430 Programmer off, wait 15 seconds
or more, and power the Model 430 Programmer back on.
When powering the system off, first turn off the power supply controlled by
the Model 430 Programmer followed by the Model 430 Programmer. The
controller will then ensure the load sees no abnormal power transients as
the power supply is turning off.
3.1.2 Energizing Power Supply and Components
Warning
Do not change power supply jumpers, dip-switches, or other factory
settings. If not rack-mounted, always position power supplies and
Model 601 Energy Absorbers for convenience in disconnecting the
power cords.
3.1.2.1 Power Supply
Place the power supply switches in the ON position. No local (front
panel) adjustments or connections are required since the power
supply control mode and other parameters have been factory-
configured for control by the AMI Model 430 Power Supply
Programmer.
When powering the system off, turn OFF the power supplies before
powering off the Model 430 Programmer.
3.1.2.2 Energy Absorber
The Model 601 Energy Absorbers are operational immediately upon
connection to a power receptacle. Power is supplied to the Model
601’s by connecting the supplied external DC power converter to
the matching connector at the rear of the Model 601, and then
connecting the AC power cord to the appropriate power receptacles.
AMI Model 430 Programmer
FAILURE TO LOAD.
