16 Rev. 5
Installation
Power Requirements
the cathode at the positive (+) terminal. Removal or omission of this
protective diode may cause serious injury to personnel and damage
to the power supply under loss of AC power conditions.
a. Connect (19) the Model 601 parallel hardware bus between Model
601 current terminals, plus-to-plus and minus-to-minus.
b. Connect (18) the power supply parallel hardware bus between
power supply current terminals, plus-to-plus and minus-to-minus.
a. Connect the protective diode between the output bus bars of the
power supply: anode to the negative (–) bus bar and the cathode to
the positive (+) bus bar.
b. Connect the positive (+) output bus (1) of the power supply to the
Model 601 Energy Absorber positive (+) bus (2).
c. Connect the negative (−) bus (3) of the Model 601 Energy Absorber
to the positive (+) magnet current lead (4).
d. Connect the negative (−) magnet current lead (5) to the positive (+)
resistive shunt terminal (6) on the back of the Model 430
Programmer.
e. Connect the negative (−) resistive shunt terminal (7) of the Model
430 Programmer to the negative (–) output bus of the power supply
(8).
f. Connect Model 05100PS Master unit terminal block positions S+,
S-, and CS to their corresponding positions (18) on the Slave unit
terminal block.
g. Connect two jumpers (17) from terminal block position S- to M- and
from S+ to M+ on the Master
1
power supply unit.
h. Connect the special DB15 analog I/O cable from the PROGRAM
OUT connector (14) on the back of the Model 430 Programmer to
the DB15 ANALOG I/O connectors (9) on the rear of the Master and
(20) Slave power supply units.
i. Install an instrumentation cable between the magnet support
stand top plate connector (10) and one of the MAGNET STATION
connectors (16) on the rear of the Model 430 Programmer.
1. Do not add terminal block jumpers to the slave units. Only the single or master unit
is jumpered.
