American Magnetics 05100PS-430-601 High Stability Integrated Power Supply System - Manual (Page 224)

206 Rev. 5
Index
RS-232 110, 177
O
operating modes
bipolar 10
dual-quadrant 10
operating voltage, changing 14
operation 25
operational limits 94
P
password 65, 71
persistent mode
entering 82
exiting 85
viewing established magnet current 36,
86
persistent switch
abbreviations 163
beep 34
control 81
cooled
time 31, 33, 34, 58, 60,
83, 90, 95
cooling 29, 35, 60, 61, 80, 83,
88, 148
cooling gain 31, 34, 35, 58, 61,
95, 148
current 59
current detect 58
defaults
cooling gain 35
cooling period 35
heating period 34
heated time 31, 34, 58, 59, 82,
84, 87, 95
heating 14, 29, 34, 44, 60, 80,
82, 89, 93, 94
heating current 31, 34, 58, 59
installed? 58, 99, 117
not installed on magnet 18, 53
pswitch
p/s ramp rate 21
ramp rate 31, 33, 34, 38, 58,
60, 83, 86, 118
settings lock 70, 123
power supply
bipolar high-stability 15
compatibility 49
displayed current 22
displayed voltage 28
general description 3
operating characteristics 10
precise control of current 3
ps unit details 167
ps unit front panel layout 7
system integral components 1
system interconnects 15
system rack layout 4
system terminology 161
system troubleshooting 139
unipolar > bipolar 173
voltage-voltage mode 3
power up/down sequence 25
powering system off 26
powering system on 25
power-up test 20
programmed current 35
protection
password 64, 71
protective diode
power supply 17
pswitch - see persistent switch
Q
quench detection 64, 90
disabling 61, 91
enabling 61
external
in/out 91, 156
indicator 29
switch failure 92
quench rate 64
quench, magnet xvi
R
ramp modes 80
ramp rate time units 63
ramp segments 63
rampdown, external - see external rampdown
ramping
automatic ramping 80
basic relationships 79
direct current manipulation 81
example 89
manual increment or decrement 80
mode symbols 29
ramp to zero 81
segmented 38, 39, 40, 63, 66,
79, 81, 102, 120, 124,
125, 126, 127, 128,
158
states 79, 129
remote control application
command interface 196
controls Model 430 194
frequently asked questions 196
IP address 195
links 196
mirrored control 194
system name 195
view of Model 430 196
web browser depiction 194
remote interface reference - see command
return authorization 149
RJ-45 connector - see Ethernet
routine maintenance 139
