Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Spindle lock button
2 Vibration damper
3 On/Off switch
4 Auxiliary handle (insulated gripping surface)
5 Grinder spindle
6 Protection guard for grinding
7 Encoding key
8 Clamping lever for protection guard
9 Screw for adjustment of protection guard
10 Mounting flange with O-ring
11 Grinding wheel*
12 Clamping nut
13 Quick-clamping nut *
14 Carbide grinding head*
15 Protection guard for cutting*
16 Cutting disc*
17 Hand guard**
18 Rubber sanding plate*
19 Sanding sheet*
20 Round nut*
21 Cup brush*
22 Cutting guide with dust extraction protection guard *
23 Diamond cutting disc*
24 Handle (insulated gripping surface)
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are: Sound pressure level 93 dB(A); Sound power level 104 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Angle Grinder GWS ... 24-230 JVX 24-230 JVX
Article number 3 601 ... H64 Z..
H64 5..
H64 U..
Rated power input W 2400 2400
Output power W 1600 1600
Rated speed min -1 6500 6500
Grinding disc diameter, max. mm 230 230
Thread of grinder spindle M 14 M 14
Thread length (max.) of grinder spindle mm 18 18
Restarting Protection – 
Reduced starting current  
Rotatable main handle  
Run-on Brake  
Weight according to EPTA-Procedure 01/2003
– with vibration-damping auxiliary handle
– with standard-auxiliary handle
kg
kg 6.5
6.4 6.6
6.5
Protection class / II / II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Only for power tools without reduced starting current: Starting cycles generate brief voltage drops. Interference with other equipment/machines may
occur in case of unfavourable mains system conditions. Malfunctions are not to be expected for system impedances below 0.25 ohm.
3 601 ... H64 Z.. H64 5.. H64 U..
Vibration total values a
h
(triax vector sum) and uncertainty K determined accord-
ing to EN 60745:
Surface grinding:
a
h
K
Disk sanding:
a
h
K
m/s 2
m/s 2
m/s 2
m/s 2
6.5
1.5
3.5
1.5
6.5
1.5
3.5
1.5
6.5
1.5
3.5
1.5
