190-00709-00 Rev. A Garmin G1000 Pilot’s Guide for the Socata TBM 850 5-39
FLIGHT MANAGEMENT
NDB
S
The NDB Information Page is used to view information about NDBs. In addition to displaying a map of
the currently selected NDB and surrounding area, the page displays NDB information in four boxes labeled
‘NDB’, ‘INFORMATION’, ‘FREQUENCY’, and ‘NEAREST AIRPORT.
Figure 5-38 NDB Information Page
Selected NDB
Navigation Map
Showing Selected
NDB
NDB Identifier/Type
- Facility Name
- Nearest City
Nearest Airport Info
- Identifier/Type (symbol)
- Bearing/Distance to
Airport
NDB Information
- Type
- Region
- Lat/Long
NDB Frequency
NOTE: Compass locator (LOM): a low power, low or medium frequency radio beacon installed in conjunction
with the instrument landing system. When LOM is used, the locator is at the Outer Marker; when LMM is
used, the locator is at the Middle Marker.
Select an NDB:
1) With the NDB Information Page displayed, enter an identifier, the name of the NDB, or the city in which it’s
located in the NDB Box.
2) Press the ENT Key.
3) Press the FMS Knob to remove the flashing cursor.
Or :
1) With the Nearest NDB Page displayed, enter an identifier, the name of the NDB, or the city in which it’s located
in the NDB Box.
2) Press the ENT Key.
3) Press the FMS Knob to remove the flashing cursor.
