The GPS 155XL’s approach select page allows you to review the available approach pro-
cedures at the destination airport. From the procedures list, you may select and activate a new
procedure on the fly. The active approach is indicated by an on-screen asterisk, and the
scrolling arrow prompt indicates which direction to scroll to view additional procedures.
To select or replace a procedure from the approach select page:
1. Press the R key and rotate O until the approach select page appears.
2. To review all available procedures, rotate
K
. “Unkn” (unknown) is displayed on
the Approach Select Page when the unit software does not know how to display
a new approach type in the database. DO NOT USE THIS APPROACH TYPE.
3. To review all available procedures, rotate K .
4. To select a procedure, press
C
and rotate
O
to highlight the desired procedure.
5. Press
E
. If there are multiple IAFs for the selected approach, rotate
O
to select the
desired IAF and press
E
.
You may also replace or delete the active approach from the route catalog page.
To replace or delete an approach from the route catalog page:
1. Press the
R
key and rotate
O
until the route catalog page appears.
2. Press C and rotate K until the ‘approach?’ prompt appears. Press E .
3. To replace the active approach procedure, rotate O to highlight the desired procedure
and press
E
. If there are multiple IAFs for the selected approach, rotate
O
to select
the desired IAF and press
E
.
4. To delete the active approach (denoted by an asterisk), highlight the approach and press
\
, followed by
E
. 85
SECTION
5
APPROACH NAV
Approach Select
Page
Approach Select Page
The Approach Select Page after deleting the
active approach. If direct-to navigation to a
SID/STAR/Approach waypoint is active when
the procedure is deleted, the direct-to waypoint
will be retained as an “off route” destination.
