The GPS 155XL’s route catalog page is used to create, edit, delete or copy routes,
and serves as the main page for a host of functions. These include route activation,
determining the closest point of approach and search-and-rescue operations. It also
displays a summary of routes currently stored in memory, with the departure and
arrival route waypoints and total distance for the selected route number. To scroll
through the available routes, rotate
K. A one-line user comment may be added to
any storage route, which will be displayed on the route catalog page.
To add user comments to any route (except route 0):
1. Rotate
K
to display the route you would like to add comments to.
2. Press C and use O to highlight the bottom row.
3. Use
K
and
O
to enter comments, and press
E
. To erase press
\
, then
E
.
The route action field, located at the top right of the page, is used to select the
desired route operation. The following functions are available:
• Activate - activate the route for navigation
• Reverse - activate a route in reverse order
• Edit - create a new route, or edit an existing route
• Approach - select an approach for the route (see Section 5)
• Star -
select a STAR for the route (see Section 5)
• Sid - select a SID for the route (see Section 5)
• Delete - delete a route
• Copy - copy the current route to an empty route
• CPA -
calculate the closest point of approach
• Search - perform search-and-rescue ladder operations
• RAIM prd - evaluate enroute RAIM availability over the entire route
62
SECTION
4
ROUTE NAV
Route Catalog Page
2 1
4 5 3
Route Catalog Page
1. Route selection field
2. Route action field
3. Departure/Arrival waypoints
4. Cumulative distance of route
5. Comments/Parallel track offset field
{
