Chapter 8. Multiple Monitors, PTZ & Keyboard
In order to perform PTZ movements, you have to select a particular live channel which contains
an IP Fast Dome. Once an IP Fast dome is selected, you can control the movements using PC
keyboard and/or PTZ control Panel.
Chapter 8-1. Preset Point Settings
To setup preset points, please invoke Presets dialog box. Follow the following
steps:
Step 1. Select preset point dropdown list.
Step 2. Type the time field.
Step 3. Type the speed field.
Step 4. Click up, down, left, or right to move the IP Fast Dome to specific position.
Step 5. Click Apply button to set the position.
PTZ control
IRIS control
Focus control
Speed control
Zoom control
control
Auto pan
control
Preset settings
Preset points
