6.0. Communication Protocol
In the normal operation, the AET63 acts as a slave device with regard to the communication between
a computer and the reader. The communication is carried out in the form of successive command-
response exchanges. The computer transmits a command to the reader and receives a response
from the reader after the command has been executed. A new command can be transmitted to the
AET63 only after the response to the previous command has been received.
There are two cases where the reader transmits data without having received a command from the
computer, namely, the Reset Message of the reader and the Card Status Message.
6.1. Command
6.1.1. Normal Command (Length < 255 bytes)
A command consists of four protocol bytes and a variable number of data bytes and has the following
structure:
Byte 1 2 3 4 ... N+3 (0
Header Instruction Data length =
N
Data Checksum
Header 01
H
to indicate the start of a standard command.
02
H
to indicate the start of an encrypted command (support from firmware 0.67
onwards, only used in PTVerifySC
(*)
and PTVerifySCAll
(*)
)
Instruction The instruction code of the command to be carried out by the AET63
Data Length Number of subsequent data bytes.(0 < N < 255)
Data Data contents of the command.
For a READ command, for example, the data bytes would specify the start address
and the number of bytes to be read. For a WRITE command, the data bytes would
specify the start address and the data to be written to the card.
The data bytes can represent values to be written to a card and/or command
parameters such as an address, a counter, etc.
Checksum The checksum is computed by XORing all command bytes including header,
instruction, data length and all data bytes.
Note (*) : Please refer to “BioTRUSTKey API Manual.doc” for the descriptions of PTVerifySC
and PTVerifySCAll.
The following example shows the structure of a command with instruction code = 91
H
and three data
bytes with the values 11
H
, 22
H
and 33
H
, respectively:
Byte 1 2 3 4 5 6 7
01
H
91
H
03
H
11
H
22
H
33
H
93
H
