7.0. COMMANDS
The commands executed by the AET63 can generally be divided into two categories, namely, Control
Commands and Card Commands.
Control Commands manage the internal operation of the AET63. They do not directly affect the card
inserted in the reader and are therefore independent of the selected card type.
Card Commands are directed toward the card inserted in the AET63. The structure of these
commands and the data transmitted in the commands and responses depend on the selected card
type.
7.1. Control Commands
7.1.1. GET_ACR_STAT
This command returns relevant information about the particular AET63 model and the current
operating status, such as, the firmware revision number, the maximum data length of a command and
response, the supported card types, and whether a card is inserted and powered up.
Command format
Instruction
Code
Data length
01
H
00
H
Response data format
INTERNAL MAX_C MAX_R C_TYPE C_SEL C_STAT
INTERNAL 10 bytes data for internal use only
MAX_C The maximum number of command data bytes.
MAX_R The maximum number of data bytes that can be requested to be transmitted in a
response.
C_TYPE The card types supported by the AET63. This data field is a bitmap with each bit
representing a particular card type. A bit set to '1' means the corresponding card type
is supported by the reader and can be selected with the SELECT_CARD_TYPE
command. The bit assignment is as follows:
byte 1 2
card type 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
See Appendix A for the correspondence between these bits and the respective card
types.
C_SEL The currently selected card type as specified in a previous SELECT_CARD_TYPE
command. A value of 00
H
means that no card type has been selected.
C_STAT Indicates whether a card is physically inserted in the reader and whether the card is
powered up:
00
H
: no card inserted
01
H
: card inserted, not powered up
03
H
: card powered up
