7.3.3. TFM_SMARTCARD 3. TFM_SMARTCARD
This is used to get list of APDUs from the EEPROM and then send the APDUs to the smart card. The
list of APDUs selects the correct file in the smart card for the enrollment or verification of the
fingerprint template. This is used to get list of APDUs from the EEPROM and then send the APDUs to the smart card. The
list of APDUs selects the correct file in the smart card for the enrollment or verification of the
fingerprint template.
Command format Command format
Instruction
Code
Data length Data
LEN ADDR
9E
H
02
H
ADDR Address of the EEPROM stores the list of APDUs. Please refer to the “Application
Notes for Handling Fingerprint Template in AET63” for detailed information
AET63 Reference Manual
Version 2.2
Page 18 of 26
[email protected]
www.acs.com.hk
Response data format
No response data
Address 0x7F00
Address 0x0900
Address 0x0800
Address 0x0700
Address 0x0600
Address 0x0500
Address 0x0400
Address 0x0300
Address 0x0200
Address 0x0000
Enroll (256 bytes max)
Address 0x0100
RECORD 0
Verify (256 bytes max)
Enroll (256 bytes max)
RECORD 1
Verify (256 bytes max)
Enroll (256 bytes max)
RECORD 2
Verify (256 bytes max)
Enroll (256 bytes max)
RECORD 3
Verify (256 bytes max)
Enroll (256 bytes max)
RECORD 4
Verify (256 bytes max)
Key Encryption Key (24 bytes)
