5.0. USB Interface
The AET63 is connected to a computer through a USB following the USB standard.
5.1. Communication Parameters
The AET63 is connected to a computer through USB as specified in the USB Specification.
The AET63 is working in low speed mode, i.e. 1.5 Mbps.
USB Interface Wiring
Pin Signal Function
1 V
BUS
+5V power supply for the reader
2 D- Differential signal transmits data between AET63 and PC.
3 D+ Differential signal transmits data between AET63 and PC.
4 GND Reference voltage level for power supply
NOTE: In order for the AET63 to function properly through USB interface, either ACS proprietary
device drive or ACS PC/SC device driver has to be installed. Please refer to the Device Driver
Installation Guide for more detail.
