67
H
= error detected in command execution
FF
H
= status message initiated by the reader
SW2 Further qualification of the command execution status.
A table listing the possible values of the status bytes SW1 and SW2 and the
corresponding meaning is given in Appendix B.
Data Length Number of subsequent data bytes (0 < N < 255)
Data Data contents of the command.
For a READ_DATA command, for example, the data bytes would contain the
contents of the memory addresses read from the card. The data bytes can represent
values read from the card and/or status information.
Checksum The checksum is computed by XORing all response bytes including header, status
bytes, data length and all data bytes.
Note (*) : Please refer to “BioTRUSTKey API Manual.doc” for the descriptions of PTVerifySC
and PTVerifySCAll.
The following example shows the structure of the response to a command which has successfully
been executed and which returns three data bytes with the values 11
H
, 22
H
and 33
H
, respectively:
Byte 1 2 3 4 5 6 7 8
01
H
90
H
00
H
03
H
11
H
22
H
33
H
92
H
6.2.2. No Transmission Error with Extended Response
The response by the AET63 to a correctly received command consists of three protocol bytes, two
status bytes and a variable number of data bytes and has the following structure:
Byte 1 2 3 4 5 6 7 ... N+6
(N>0)
N+7
Header SW1 SW2 Data length = N Data Checksum
FF
H
Data Length
N
Header 01
H
to indicate the start of the normal response.
02
H
to indicate the start of an encrypted response (support from firmware 0.67
onwards, only used in PTVerifySC
(*)
and PTVerifySCAll
(*)
)
SW1 Indicates the command execution status:
90
H
= command successfully executed
60
H
= error in command data; command cannot be executed
67
H
= error detected in command execution
FF
H
= status message initiated by the reader
SW2 Further qualification of the command execution status.
A table listing the possible values of the status bytes SW1 and SW2 and the
corresponding meaning is given in Appendix B.
Data Length Number of subsequent data bytes, and is encoded in 3 bytes. The first byte is FF
H
.
The second byte and the third byte represent data length N.
Document Title Here Document Title Here
Document Title Here AET63 Reference Manual
Version 2.2
Page 10 of 26
