10 fan tunnel ins tallation – Acnodes PC 8177 User Manual
Page 30
2.10
Fan Tunnel Ins tallation
The PC8177 provides one fan tunnel to install. W hen installing the fan tunnel, refer to the
following instructions and illustration:
Step1
Spread the fan tunnel out flat.
Step2
Tear the releasing paper from the dual face tape.
Step3
Fold each curved line.
Step4
Stick each side together.
Step5
Let fan cable through the fan tunnel and stick to the cooler.
