RMC 7155

14” short depth server

All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.

14628 Central Blvd,

Chino, CA91710

tel:909.597.7588, fax:909.597.1939

Installing a Passive CPU Heatsink

1. Place the heatsink on top of the CPU so that the four
mounting holes are aligned with those on the retention
mechanism.

2. Install two diagonal screw and tighten them until
just snug.

3. Repeat steps 2 with the #3 and #4 screws. Make sure
all screws are snug.
