RED pushbutton

GREEN pushbutton

BLUE pushbutton

CYAN pushbutton

MAGENTA pushbutton

YELLOW pushbutton

WHITE pushbutton

AMBER pushbutton

AUTO pushbutton

UNIT SETTING pushbutton

PATTERN/RED key

SPEED/GREEN key

FADE/BLUE key

BRIGHTNESS key

Red, 100% brightness

Green, 100% brightness

Blue, 100% brightness

Cyan, 100% brightness

Magenta, 100% brightness

Yellow, 100% brightness

White, 100% brightness

Amber, 100% brightness

The color is changing automatically, and the brightness is 100%.

Cancel the infrared remote operations. All settings will be done by flipping
dip-switches.

Select next pattern / increase red brightness.
Holding the key down will gradually increase the brightness to its maximum value.

Select previous pattern / decrease red brightness.
Holding the key down will gradually decrease the brightness to its minimum value.

Increase speed/ increase green brightness.
Holding the key down will gradually increase the brightness to its maximum value.

Decrease speed / decrease green brightness.
Holding the key down will gradually decrease the brightness to its minimum value.

Increase fadetime/ increase blue brightness.
Holding the key down will gradually increase the brightness to its maximum value.

Decrease fadetime / decrease blue brightness.
Holding the key down will gradually decrease the brightness to its minimum value.

Increase master brightness.
Holding the key down will gradually increase the brightness to its maximum value.

Decrease master brightness.
Holding the key down will gradually decrease the brightness to its minimum value.

ON/OFF pushbutton

Power ON/OFF

Pushbuttons&Keys

Functions

NOTE:
1.The built-in patterns consists of
2.There are optional 10 different levels for chase speed;

1~10 patterns plus a sequence of 10 patterns.

Speed

Time

16S

32.5S

65S

130S

260S

512S

3.And fade time is available from 0% through 100%, total 11levels, 10% per level.

4.Effective distance from IR EYE(sensor) to LED Remote shall be limited within the range of 10m. Otherwise, it
results out of control.
