Acclaim Lighting Pixel Driver Mini User Manual
Pixel driver mini, Descriptions, Delivery packet

Descriptions:
Congratulations with your purchase of this product.
The Pixel Driver Mini is intended to design for our product PS-5/PS-10. As a LED driver, the
features DMX addresses are assigned automatically and the value of controlling pixel is selectable. The Red,
Green and Blue of each pixel can be controlled separately as well.
Pixel Driver Mini
Check for transport damage.
You should be in possession of the following items:
1
1 Manual
1 First Cable
1 Screw Driver
1 Connecting Part
Should you discover transport damage after unpacking the equipment, inform the hauler immediately. Never
connect a damaged device. You may also contact your supplier.
Pixel Driver Mini
Delivery Packet:
Pixel Driver Mini
Pixel Driver Mini
Main Features:
Technical Specifications:
Operation temperature
Connection
Housing
Ingress Protection Rating
Control Protocol
Listing
Dimensions
Weights
-10 degC to +50 degC
DMX In via 3-pin Terminal
DMX Out via 3-pin Terminal
PC +UV resistance
Indoor Use Only
Compatible DMX-512 (1990) and DMX-1000K(1M)
CE certified
90(L) x 43(W) x 20(H)mm
35g
Operation Voltage
DC 5V
LED driver idea design for color mixing (PS-5/PS-10).
Compatible for DMX-512(1990) and DMX-1000K(1M).
Automatically DMX addressing.
LED Display.
The value of controlling pixel is selectable(5~200).
-170 pixels can be linked up via DMX-512
-600 pixels can be linked up via DMX-1000K(1M)
*Please Note: Improvements and specifications in the design of the unit and the manual are subject to change
without any prior written notice.
-Page 1-
*Special Note: For reducing signal errors and avoiding signal transmission problems and interference,it is always
advisable to connect 120 ohm impedance DMX signal cable and DMX terminal for signal connection.
Power In via 2-pin Terminal
Output via 6-pin Terminal
