Bosch FLM-420-EOL2W-W EOL Module LSN - Manual (Page 5)

5
| |
A 8 7 6 5 4 3 2 1 A 8 7 6 5 4 3 2 1 A 8 7 6 5 4 3 2 1
0 0 0 0 0 0 0 0 0 42 42 00 00 11 00 11 00 11 00 85 0 1 0 1 0 1 0 1
255=CL 1 1 1 1 1 1 1 1 43 0 0 1 0 1 0 1 1 86 0 1 0 1 0 1 1 0
1 0 0 0 0 0 0 0 1 44 0 0 1 0 1 1 0 0 87 0 1 0 1 0 1 1 1
2 0 0 0 0 0 0 1 0 45 0 0 1 0 1 1 0 1 88 0 1 0 1 1 0 0 0
3 0 0 0 0 0 0 1 1 46 0 0 1 0 1 1 1 0 89 0 1 0 1 1 0 0 1
4 0 0 0 0 0 1 0 0 47 0 0 1 0 1 1 1 1 90 0 1 0 1 1 0 1 0
5 0 0 0 0 0 1 0 1 48 0 0 1 1 0 0 0 0 91 0 1 0 1 1 0 1 1
6 0 0 0 0 0 1 1 0 49 0 0 1 1 0 0 0 1 92 0 1 0 1 1 1 0 0
7 0 0 0 0 0 1 1 1 50 0 0 1 1 0 0 1 0 93 0 1 0 1 1 1 0 1
8 0 0 0 0 1 0 0 0 51 0 0 1 1 0 0 1 1 94 0 1 0 1 1 1 1 0
9 0 0 0 0 1 0 0 1 52 0 0 1 1 0 1 0 0 95 0 1 0 1 1 1 1 1
10 0 0 0 0 1 0 1 0 53 0 0 1 1 0 1 0 1 96 0 1 1 0 0 0 0 0
11 0 0 0 0 1 0 1 1 54 0 0 1 1 0 1 1 0 97 0 1 1 0 0 0 0 1
12 0 0 0 0 1 1 0 0 55 0 0 1 1 0 1 1 1 98 0 1 1 0 0 0 1 0
13 0 0 0 0 1 1 0 1 56 0 0 1 1 1 0 0 0 99 0 1 1 0 0 0 1 1
14 0 0 0 0 1 1 1 0 57 0 0 1 1 1 0 0 1 100 0 1 1 0 0 1 0 0
15 0 0 0 0 1 1 1 1 58 0 0 1 1 1 0 1 0 101 0 1 1 0 0 1 0 1
16 0 0 0 1 0 0 0 0 59 0 0 1 1 1 0 1 1 102 0 1 1 0 0 1 1 0
17 0 0 0 1 0 0 0 1 60 0 0 1 1 1 1 0 0 103 0 1 1 0 0 1 1 1
18 0 0 0 1 0 0 1 0 61 0 0 1 1 1 1 0 1 104 0 1 1 0 1 0 0 0
19 0 0 0 1 0 0 1 1 62 0 0 1 1 1 1 1 0 105 0 1 1 0 1 0 0 1
20 0 0 0 1 0 1 0 0 63 0 0 1 1 1 1 1 1 106 0 1 1 0 1 0 1 0
21 0 0 0 1 0 1 0 1 64 0 1 0 0 0 0 0 0 107 0 1 1 0 1 0 1 1
22 0 0 0 1 0 1 1 0 65 0 1 0 0 0 0 0 1 108 0 1 1 0 1 1 0 0
23 0 0 0 1 0 1 1 1 66 0 1 0 0 0 0 1 0 109 0 1 1 0 1 1 0 1
24 0 0 0 1 1 0 0 0 67 0 1 0 0 0 0 1 1 110 0 1 1 0 1 1 1 0
25 0 0 0 1 1 0 0 1 68 0 1 0 0 0 1 0 0 111 0 1 1 0 1 1 1 1
26 0 0 0 1 1 0 1 0 69 0 1 0 0 0 1 0 1 112 0 1 1 1 0 0 0 0
27 0 0 0 1 1 0 1 1 70 0 1 0 0 0 1 1 0 113 0 1 1 1 0 0 0 1
28 0 0 0 1 1 1 0 0 71 0 1 0 0 0 1 1 1 114 0 1 1 1 0 0 1 0
29 0 0 0 1 1 1 0 1 72 0 1 0 0 1 0 0 0 115 0 1 1 1 0 0 1 1
30 0 0 0 1 1 1 1 0 73 0 1 0 0 1 0 0 1 116 0 1 1 1 0 1 0 0
31 0 0 0 1 1 1 1 1 74 0 1 0 0 1 0 1 0 117 0 1 1 1 0 1 0 1
32 0 0 1 0 0 0 0 0 75 0 1 0 0 1 0 1 1 118 0 1 1 1 0 1 1 0
33 0 0 1 0 0 0 0 1 76 0 1 0 0 1 1 0 0 119 0 1 1 1 0 1 1 1
34 0 0 1 0 0 0 1 0 77 0 1 0 0 1 1 0 1 120 0 1 1 1 1 0 0 0
35 0 0 1 0 0 0 1 1 78 0 1 0 0 1 1 1 0 121 0 1 1 1 1 0 0 1
36 0 0 1 0 0 1 0 0 79 0 1 0 0 1 1 1 1 122 0 1 1 1 1 0 1 0
37 0 0 1 0 0 1 0 1 80 0 1 0 1 0 0 0 0 123 0 1 1 1 1 0 1 1
38 0 0 1 0 0 1 1 0 81 0 1 0 1 0 0 0 1 124 0 1 1 1 1 1 0 0
39 0 0 1 0 0 1 1 1 82 0 1 0 1 0 0 1 0 125 0 1 1 1 1 1 0 1
40 0 0 1 0 1 0 0 0 83 0 1 0 1 0 0 1 1 126 0 1 1 1 1 1 1 0
41 0 0 1 0 1 0 0 1 84 0 1 0 1 0 1 0 0 127 0 1 1 1 1 1 1 1
