uu Replacing Light Bulbs u Back-Up Light Bulbs
Main
tenan
ce
Back-Up Light Bulbs
When replacing, use the following bulbs.
1. Remove the screw from the center of the
fastener using a Phillips-head screwdriver.
2. Remove the holding clips using a flat-tip
screwdriver, then pull the lining back.
2 Rear Turn Signal Light Bulbs P. 274
3. Turn the socket to the left and remove it.
4. Remove the old bulb and insert a new bulb.
Taillight Bulbs
Taillight bulbs in the trunk lid are LED type. Have an authorized Honda dealer inspect
and replace the light assembly.
Back-Up Light: 16 W
Lining
Fastener
Clip
Bulb
Socket
