FRONT SEATS
WARNING
All adjustments must be made with the
car stationary.
LENGTHWISE DIRECTION ADJUSTMENT
Lift the lever A fig. 16 and push the seat forwards or
backwards: in the driving position your arms should
rest on the rim of the steering wheel.
WARNING
Once you have released the adjustment
lever, always check that the seat is
locked on the guides by trying to move it back
and forth. Failure to lock the seat in place could
result in the seat moving suddenly and the
driver losing control of the car.
ADJUSTING BACKREST INCLINATION
Turn knob B fig. 17.
HEIGHT ADJUSTMENT
(for versions/markets, where provided)
Operate lever C fig. 18 to lift or lower the rear part
of the cushion to achieve the most comfortable
driving position.
fig. 16 F0S0013 fig. 17 F0S0014
23
