FUSE SUMMARY TABLE
Dashboard fuse box fig. 126 FUSE AMPS
Right dipped headlamp power supply F12 7,5
Left dipped headlight and headlight alignment control
unit power supply
F13 7,5
Front, rear and luggage compartment roof lights F32 7,5
Diagnosis socket, radio, climate control, EOBD F36 10
Brake light switch, instrument panel node F37 5
Door central locking F38 15
Windscreen/rear window washer pump F43 15
Driver's side electric windows F47 20
Passenger side electric window F48 20
Parking sensor, control backlighting, electric mirrors F49 5
Radio switch, Blue&Me, climate control, brake lights,
clutch
F51 7,5
Instrument panel node F53 5
