12
36, 40, 44 & 48 (Europe) and channels 36, 40, 44, 48,
149, 153, 157, 161 & 165 (U.S.) If you do not see your
5GHz network listed, you may need to change your
router/access point’s 5GHz channel.
5. If the network you wish to connect to has a hidden SSID, select “Setup
extender manually” for 2.4GHz or 5GHz and enter the SSID manually. Then
input a “Device SSID” (name to identify the extender’s Wi-Fi network) and
security key information. Check the “Hide SSID” box if you wish for the
extender’s SSID to remain hidden.
6. For each network you select, you can enter a “Device SSID” which is a name
to identify the EW-7238RPD’s Wi-Fi network. If the root SSID requires a
security key, you will also be required to enter it here.
Note: If you do not know your existing network
security key, please refer to IV-1-3. How to Find Your
Network Security Key .
