A–1
A
Specifications
Appendix A contains electrical performance and physical specifications
for the XPower 1000.
Electrical Performance
Physical Specifications
Specifications are subject to change without notice.
Electrical performance XPower 1000
Output power at 77 º F (25 ºC) ambient
temperature and 12 VDC input:
• Maximum continuous output power
• 5 minutes
1000 W
1200 W
Output voltage 115 VAC RMS ± 5%
Output waveform Modified sine wave
Output frequency 60 Hz ± 4 Hz
Input voltage 10.5–15.0 VDC
Low voltage alarm 11.0 V
Low voltage cutout 10.5 V
Optimum efficiency 90%
No load current draw <0.3 ADC
Physical XPower 1000
Length 288.0 mm (11.34 inches)
Width 151.0 mm (5.94 inches)
Height 70.0 mm (2.75 inches)
Weight 1.92 kg (4.23 lb)
