Installation
3–10 975-0127-01-01
Materials The following checklist is a general list of required materials.
• Four corrosion-resistant fasteners sized #10 or larger for mounting the
inverter
• Copper DC input cable as calculated in Table 3-1 on page 3–7
• Two 1/4 inch (6 mm) ring terminals sized for the cable diameter to
connect the DC cables to the DC cabling terminal
• Lugs and terminals to connect the DC cables that connect to the
battery, Disconnect/Battery Selector switch and fuse holder(s)
• DC fuse(s) as calculated in “Calculating Fuse/Circuit Breaker Size”
on page 3–8 and fuse holder(s)
• Copper chassis ground cable as calculated in Table 3-2 on page 3–7
• Ring terminal (appropriately sized to connect copper cable to chassis
ground screw) that meets the following specifications:
• #10 screw
• UL/CSA approved
• copper
• tin-plated
• Battery isolator (if connecting to a multiple-battery system)
• Disconnect/Battery selector switch
• Alternator controller
1
• High-output alternator
1
1.Consult Appendix B, “Battery Types” and Appendix C, “Alternators and Charging
Systems” to determine whether you need these components.
