Page 44: T in figure 2.2. t
Installation
AC Input Power
42
Operating Manual for XFR 2.8kW Series Power Supply
Figure 2.2 AC Input Cover and Strain Relief
Screw-on
Locknut
Stripped Wire Installed in Strain Relief
Connector Terminal Locations
Cover
Assembled Strain
Relief
Flat Washer (2 places)
Lock Washer (2 places)
Screw (2 places)
Chassis
Ground Screw
