Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO
YHJD36S21S1
EVAPORATOR COIL MODEL NO
AHP36
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1000
1200
1400
MBTUH
KW
C.O.P.
MBTUH
KW
C.O.P.
MBTUH
KW
C.O.P.
60
60
41.6
2.4
5.0
42.2
2.3
5.3
42.7
2.2
5.6
70
40.1
2.6
4.5
40.8
2.5
4.8
41.5
2.4
5.1
80
38.6
2.8
4.1
39.5
2.7
4.3
40.4
2.6
4.6
47
60
35.3
2.3
4.6
35.5
2.2
4.8
35.7
2.1
4.9
70
33.8
2.4
4.2
34.3
2.3
4.3
34.8
2.3
4.5
80
32.4
2.5
3.7
33.1
2.5
3.9
33.8
2.4
4.1
40
60
31.4
2.2
4.2
31.4
2.1
4.4
31.5
2.0
4.5
70
30.2
2.3
3.9
30.6
2.2
4.0
31.0
2.2
4.2
80
29.1
2.4
3.5
29.8
2.4
3.7
30.4
2.3
3.8
30
60
27.4
2.0
3.9
27.3
2.0
4.0
27.3
2.0
4.1
70
26.1
2.1
3.6
26.4
2.1
3.7
26.7
2.1
3.8
80
24.9
2.2
3.3
25.5
2.2
3.4
26.1
2.2
3.5
17
60
21.4
1.9
3.4
21.5
1.8
3.4
21.7
1.8
3.5
70
19.9
1.9
3.0
20.2
1.9
3.1
20.6
1.9
3.2
80
18.4
2.0
2.7
18.9
2.0
2.8
19.4
2.0
2.9
10
60
17.9
1.8
3.0
17.8
1.7
3.0
17.7
1.7
3.0
70
16.8
1.8
2.7
17.0
1.8
2.8
17.2
1.8
2.9
80
15.7
1.8
2.5
16.1
1.8
2.6
16.6
1.8
2.7
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler
Coil
MBH
KW
COP
–
FC/MC/PC/UC37
1.00 1.00 1.00
–
FC/MC/PC/UC43
1.00 1.00 1.00
–
FC/MC/PC/UC48
1.00 1.00 1.00
–
FC/MC/PC/UC60
1.00 1.00 1.00
–
HC42
1.00 1.00 1.00
–
HC60
1.00 1.00 1.00
–
HD48
1.00 1.00 1.00
–
HD60
1.00 1.00 1.00
AHP42
–
1.00 1.00 1.00
AHP/SHP60
–
0.98 1.04 0.96
F5FP045
–
1.00 1.00 1.00
F4FV060
–
0.98 1.04 0.96
F5FP048
–
0.98 1.04 0.96
F5FP060
–
0.98 1.04 0.96
AV36
–
0.98 1.04 0.96
AV/SV48
–
0.98 1.04 0.96
MV16C
FC/MC43C
0.97 1.06 0.94
MV12B
FC/MC43B
0.98 1.03 0.97
MA12B
FC/MC43B
1.00 1.00 1.00
MV16C
FC/MC48C
0.97 1.06 0.94
MV16C
FC60C
0.97 1.06 0.94
MV12D
FC/MC48D
0.97 1.06 0.94
MA14D
FC/MC48D
1.00 1.00 1.00
MV12D
FC/MC48D
0.97 1.05 0.95
MA14D
FC/MC60D
1.00 1.00 1.00
MV12D
FC/MC60D
0.97 1.06 0.94
Variable Speed
Furnace
Coil
MBH
KW
COP
PV8*A12
FC/MC/PC/UC37A 0.98 1.02 0.98
PV9*A12
FC/MC/PC/UC37A 1.00 1.00 1.00
PV8*B16
FC/MC/PC/UC43B 0.98 1.04 0.96
PV8*C16
FC/MC/PC/UC43C 0.98 1.05 0.95
PV8*C20
FC/MC/PC/UC43C 0.98 1.03 0.97
P(C,V)9*B12
FC/MC/PC/UC43B 0.98 1.02 0.98
P(C,V)9*C16
FC/MC/PC/UC43C 0.98 1.04 0.96
P(C,V)9*C20
FC/MC/PC/UC43C 0.98 1.04 0.96
PV8*C16
FC/MC/PC/UC48C 0.97 1.05 0.95
PV8*C20
FC/MC/PC/UC48C 0.98 1.03 0.97
P(C,V)9*C16
FC/MC/PC/UC48C 0.98 1.05 0.95
P(C,V)9*C20
FC/MC/PC/UC48C 0.98 1.05 0.95
P(C,V)9*D20
FC/MC/PC/UC48D 0.98 1.05 0.95
PV8*C16
HC42
0.97 1.05 0.95
PV8*C20
HC42
0.98 1.03 0.97
P(C,V)9*C16
HC42
0.98 1.04 0.96
P(C,V)9*C20
HC42
0.98 1.05 0.95
