Specifications
42 975-0328-01-01
Normal operating temperature 77 ºF
(25 ºC)
Operating temperature range 32 – 104 ºF
(0 – 40 ºC)
Storage temperature range -4 – 140 ºF
(-20 – 60 ºC)
DC Power Section
DC output power (maximum continuous load) 12 A with overload
protection and automatic
reset
DC charger input socket polarity Female, center positive
Built-in ambient LED light 12 hi-bright white LEDs
with diffuser
Internal Battery Section
Internal battery type sealed, AGM (Absorbed
Glass Mat) lead acid
Internal battery voltage (nominal) 12 Vdc
Internal battery capacity (minimum) 10 Ah
Maximum charge current 0.75 Adc
Peak charging voltage (nominal) 14.8 V
Charge restart voltage (nominal) 12.8 V
Low battery alarm 11.0 Vdc
Low battery shutdown 10.5 Vdc
High battery voltage shutdown 15.5 Vdc
USB Section
Output Voltage (No Load) 5 Vdc
Output Voltage current 500mAdc
