Xantrex Technology Solar 400 - Manual (Page 57)

41
A
Specifications
Chapter A, “Specifications” includes the electrical,
mechanical, and environmental specifications for the
Powerpack Solar 400.
Electrical Specifications
AC Power Section
Output power
•
Continuous output power
• Peak AC output power
• AC output surge capacity
320 W
400 W
640 W
Output voltage 115 ± 10 Vac RMS
Output frequency 60 Hz ± 1 Hz
Output wave form
Total Harmonic Distortion (THD)
Maximum Single Harmonic
modified sine wave
(non-sinusoidal)
32.7%
30%
No load current draw <0.40 Adc
Input voltage range 10.5 to 15.5 Vdc
Over temperature shutdown feature Yes, automatic reset
Overload shutdown feature Yes, automatic reset
AC output short circuit protection feature Yes, automatic reset
Fuse (internal, non-replaceable) 2 × 25 A
