Powerpack Solar 400 Features
975-0328-01-01 7
Solar Panel Components
Figure 2-5 Solar Panel Component
Feature Description
The male/female connectors attach to each other and connect the
solar panel to the charging assembly inside the unit.
You can remove the solar panel by unplugging the male/female
connectors.
The Indicator Light flashes when the panel is receiving power
from sunlight.
The Solar Panel is rated at 5 W and made of amorphous silicon
material. The panel can be detached from the unit and extended up
to one meter with its electrical cord.
Note : Detaching the solar panel allows you to reposition it and
not the whole unit for optimum sunlight exposure.
1
2
3
mounting clamp
for securing the
solar panel
1
2
3
