Function settings Reference
DGX-505/305 Owner’s Manual
71
■ Function Display List
Category Setting Item title Range/Settings Description
VOLUME Style Volume Style Volume 000 – 127 Determines the volume of the Style.
Song Volume Song Volume 000 – 127 Determines the volume of the Song.
OVERALL Transpose Transpose -12 – 12 Determines the pitch of the instrument by semitone
increments.
Tuning Tuning -100 – 100 Sets the pitch of the instrument’s sound in 1-cent
increments.
Pitch Bend Range Pitch Bend
Range 01 – 12 Sets the pitch bend range in semitone increments.
Split Point Split Point 000 – 127 (C-2 – G8) Determines the highest key for the Split voice and
sets the Split “point” — in other words, the key that
separates the Split (lower) and Main (upper) voices.
The Split Point setting and Accompaniment Split
Point setting are automatically set to the same value.
Touch Sensitivity Touch
Sensitivity 1 (Soft)/2 (Medium)/
3 (Hard) When Touch Response is on, this determines the
sensitivity of the feature.
MAIN VOICE Volume M. Volume 000 – 127 Determines the volume of the Main voice.
Octave M. Octave -2 – +2 Determines the octave range for the Main voice.
Pan M. Pan 000 (left) – 64 (center)
– 127 (right) Determines the pan position of the Main voice in the
stereo image. The value “0” results in the sound
being panned full left; the value “127” results in the
sound being panned full right.
Reverb Send Level M. Reverb Level 000 – 127 Determines how much of the Main voice’s signal is
sent to the Reverb effect.
Chorus Send Level M. Chorus Level 000 – 127 Determines how much of the Main voice’s signal is
sent to the Chorus effect.
DUAL VOICE Volume D. Volume 000 – 127 Determines the volume of the Dual voice.
Octave D. Octave -2 – +2 Determines the octave range for the Dual voice.
Pan D. Pan 000 (left) – 64 (center)
– 127 (right) Determines the pan position of the Dual voice in the
stereo image. The value “0” results in the sound
being panned full left; the value “127” results in the
sound being panned full right.
Reverb Send Level D. Reverb Level 000 – 127 Determines how much of the Dual voice’s signal is
sent to the Reverb effect.
Chorus Send Level D. Chorus Level 000 – 127 Determines how much of the Dual voice’s signal is
sent to the Chorus effect.
SPLIT VOICE Volume S. Volume 000 – 127 Determines the volume of the Split voice.
Octave S. Octave -2 – +2 Determines the octave range for the Split voice.
Pan S. Pan 000 (left) – 64 (center)
– 127 (right) Determines the pan position of the Split voice in the
stereo image. The value “0” results in the sound
being panned full left; the value “127” results in the
sound being panned full right.
Reverb Send Level S. Reverb Level 000 – 127 Determines how much of the Split voice’s signal is
sent to the Reverb effect.
Chorus Send Level S. Chorus Level 000 – 127 Determines how much of the Split voice’s signal is
sent to the Chorus effect.
EFFECT Reverb Type Reverb Type 01 – 10 Determines the Reverb type, including off (10). (See
the list on page 104)
Chorus Type Chorus Type 01 – 05 Determines the Chorus type, including off (05). (See
the list on page 104)
Panel Sustain Sustain ON/OFF Determines whether or not panel sustain is always
applied to the MAIN/DUAL/SPLIT voices. Panel sus-
tain is applied continuously when ON, or not applied
when OFF. (page 58)
HARMONY Harmony Type Harmony Type 01 – 26 Determines the Harmony type. (See the list on page
104)
Harmony Volume Harmony
Volume 000 – 127 Determines the level of the Harmony effect when
Harmony type 1-5 is selected.
