PM5D/PM5D-RH V2 / DSP5D Owner’s Manual

Reference section

283

Information shown

in the display

Function

menu

Global

functions

Output

functions

Input

functions

Appendices

Here you can recall, store, rename, or delete items in the
input patch library.

Except for the fact that these are patch settings for input
channels, display and operations are the same as in the
OUTPUT PATCH function OUTPUT PATCH LIBRARY
screen. Refer to p.247.

INPUT HA/INSERT function

Here you can make settings for internal HAs (PM5D-RH
model only) or external HAs assigned to input channels.

INPUT PATCH LIBRARY screen

INPUT PATCH LIBRARY

CH 1-24 (Input channel 1-24) screen

CH 25-48 (Input channel 25-48)
screen

STIN/FXRTN (ST IN/FXRTN channel)
screen

CH 1-24

STIN/FXRTN
