255029-YTG-M-0610
6 Johnson Controls Unitary Products
PHYSICAL & ELECTRICAL DATA
Models AHP18B**H21 AHP24B**H21 AHP30B**H21 AHP36C**H21
Blower - Diameter x Width 9 x 6 10 x 9 10 x 9 10 x 10
Motor
HP 1/3 HP 1/4 HP 1/2 HP 3/4 HP
Nominal RPM 1075 1075 1075 1075
Voltage 230
Amps Full Load (230) 1.9 1.5 2.2 3.6
Filter 1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 16 x 20 x 1 20 x 20 x 1
Permanent Type Kit 1PF0601BK 1PF0601BK 1PF0601BK 1PF0602BK
Shipping / Operating Weight (lbs.) - N Models 128/122 132/126 139/133 162/156
Shipping / Operating Weight (lbs.) - H Models 131/125 135/129 142/136 165/159
Models AHP42C**H21 AHP48D**H21 AHP60D**H21
Blower - Diameter x Width 10 x 10 10 x 10 11 x 10
Motor
HP 3/4 HP 3/4 HP 1 HP
Nominal RPM 1075 1075 1050
Voltage 230
Amps Full Load (230) 3.8 3.8 7.6
Filter 1
Type DISPOSABLE OR PERMANENT
Size 20 x 20 x 1 22 x 20 x 1 22 x 20 x 1
Permanent Type Kit 1PF0602BK 1PF0603BK 1PF0603BK
Shipping / Operating Weight (lbs.) - N Models 164/158
AHP - 186/175
SHP - 182/171 AHP - 189/178
SHP - 185 /174
Shipping / Operating Weight (lbs.) - H Models 167/161 190/179 193/182
1. Field Supplied.
ELECTRICAL DATA - COOLING ONLY (60 Hz)
Models
Total Motor Amps Minimum Circuit Ampacity
Max. O.C.P.
1
Amps/Type
Minimum Wire
Size A.W.G.
60 Hertz 60 Hertz
208V 230V 208V 230V
AHP18B**H21 1.7 1.9 2.1 2.4 15 14
AHP24B**H21 1.4 1.5 1.8 1.9 15 14
AHP30B**H21 2 2.2 2.5 2.8 15 14
AHP36C**H21 3.3 3.6 4.1 4.5 15 14
AHP42C**H21 3.4 3.8 4.3 4.8 15 14
AHP48D**H21 3.4 3.8 4.3 4.8 15 14
AHP60D**H21 7.6 7.6 9.5 9.5 15 14
1. OCP = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
