Appendix A Product Specifications
DMA-1000 Series User’s Guide
87
Cable Pin Assignments
Power Adaptor Specifications
Table 35 Ethernet Cable Pin Assignments
LAN ETHERNET CABLE PIN LAYOUT
Straight-through
(Switch)
(Adapter)
1 IRD +
1
OTD
+
2 IRD -
2
OTD -
3 OTD
+
3
IRD +
6 OTD -
6
IRD -
Table 36 Power Adaptor Specifications
AC Power Adaptor Model
MU12-2050200-A1
Input Power
AC 100~240 Volts/60Hz/0.25A
Output Power
DC 5 Volts/ 2A
Power Consumption
10 W
Safety Standards
UL 60950
