Chapter 1 Introducing the DMA
DMA-1000 Series User’s Guide
23
The following table describes the DMA LEDs.
Table 1 LEDs
LED
COLOR
STATUS
DESCRIPTION
STATUS
Orange
On
The DMA is receiving power and in operation mode
(on).
Green
On
The DMA is receiving power and in standby mode (off).
Off
The DMA is not receiving power.
PLAY
Green
Blinking
The DMA is playing a file.
Off
The DMA is not playing a file.
LAN
Green
On
The DMA has a successful Ethernet connection.
Blinking
The DMA is sending/receiving data on this port.
Off
The DMA does not have a connection on this port.
WLAN (DMA-
1000W only)
Green
On
The DMA has a successful wireless LAN connection.
Blinking
The DMA is sending/receiving data through the wireless
LAN connection.
Off
The DMA does not have a wireless LAN connection.
USB
Green
On
The DMA has a USB stick (or hard drive) connected.
Off
The DMA does not have a USB stick connected.
