Battery Charging
975-0467-01-01
4–13
Table 4-2 Battery Charging Status LED
Status LED
Display Screen
Condition
Solid GREEN
FUL
Battery is FULL.
Flashing
GREEN
BUL
—
CHg
—
12.8
(where 12.8 is an
example of battery
voltage)
Battery is in BULK CHARGE.
ABS
—
CHg
—
14.2
(where 14.2 is an
example of battery
voltage)
Battery is in ABSORPTION CHARGE.
Solid RED
E10
to
e12
See
Table 5-1, “Error Codes Displayed on the Display Panel
Solid GREEN
or
Flashing
GREEN
5A
or
15A
or
35A
or
55A
Select button is pressed to display present Charging Current
setting.
None of the info and setting LED lights are on.
Present setting is displayed on the screen.
IN0
or
In1
Select button is pressed to display present Inverter Mode
setting.
None of the info and setting LED lights are on.
Present setting is displayed on the screen.
aL0
or
AL1
Select button is pressed to display present Alarm setting.
None of the info and setting LED lights are on.
Present setting is displayed on the screen.
sdL
or
sdH
Select button is pressed to display present Shutdown setting.
None of the info and setting LED lights are on.
Present setting is displayed on the screen.
