Figure 5 Jumper Locations on the FacePlate and Remote
Remote Circuit Board
(backside)
Voltage
Jumpers
must match
system
voltage
Remove this jumper
for long cable runs,
dimming the display,
or conserving power.
Potentiometer for
LCD Contrast
Adjustment
Faceplate Circuit Board
(backside)
